GESIMAR TRACK MEASUREMENT AND ULTRASONIC INSPECTION TROLLEY VIGILIS 400
- Compact, self-propelled and versatile solution to automatically inspect and measure all track parameters.
- The VIGILIS 400 will allow you to perform ultrasonic inspections up to 20 kph. The user-friendly on-board system will detect and mark rails if integrity defects are detected
- The VIGILIS 400 ensures fast and accurate inspection and recording of track parameters up to a speed of 50 kph
- The cab of the VIGILIS 400 can transport up to 4 people as well as one driver for in-situ measurement and analysis of results
| Motorisation / Thermal power | 4-cylinder engine: 85 HP (diesel) |
| Transmission | Hydrostatic 4 wheel drive |
| Max. allowed load in flatbed/in towing | Up to 2 t |
| Minimum curve radius | 60 m (197 ft.) |
| Maximum slope | 5 % |
| Max. speed on rails (with trailer) | 50 kph (31 mph) |
| Maximal cant | 130 mm (5 in.) |
| Number of transducers per rail | Wheel probes: 11 |
| Number of ultrasonic channels per rail | Wheel probes: 14 |
| US testing for rail head from 50 to 80 mm | 2 mm (0.1 in.) sample rate at 10 kph (6 mph) |
| RailScan™ Lite Track Geometry Measurement System | GPS coordinates every 304 mm (12 in.) Sample rate: 250 mm (10 in.), Pitch: ± 1 mm (0.04 in.) |
| References | Metro of Cairo Egypt with model Vigilis 400 MT US for Track Geometry Measurement and Ultrasonic Rail Inspection
Metro of Bangkok Red Line / Purple Line with model Vigilis 400 US for Ultrasonic Rail Inspection |
